2D Wired Desktop Hands-free Barcode Scanner With Large Scanning Window

Performance Parameters

Image Sensor

Red LED

Supported

Symbologies

1D: Codabar, Code 39, Code 32, Interleaved 2 of 5, NEC 2 of 5,

Code 93, Straight 2 of 5, Industrial, Straight 2 of 5 IATA,

Matrix 2 of 5, Code 11, Code 128, ISBT 128, GS1-128, UPC-A,

UPC-E0, UPC-E1, EAN/JAN-13, EAN/JAN-8, ISBN, MSI,

GS1 DataBar-Omnidirectional, GS1 DataBar Limited,

GS1 DataBar Expanded.

2D: PDF417, QR code, DataMatrix, Aztec Code, China Post,

HongKong 2 of 5, Korea Post, Han Xin code, Maxi code,

Micro PDF417, GS1 Composte coders, Codablock A, Codablock F.

Scan Range

10-150mm(EAN 13 13mil, PCS=90%)

System compatibility

Linux, Android, Windows XP/7/8/10

Minimum recognition accuracy

Code 39 4mil

Image (Pixels)

640pixels(H) x 480 pixels(V)

Motion tolerance

2meters/second

Scan Mode

Automatic Induction Scanning

Man-machine Interaction

Indicator light: Blue light power indicator;
Blue light flashing code reading prompt,
Buzzer: start prompt, read code prompt.

Recognition angle range

Turn ±360°, Elevation ±65°, Declination ±65°

Communication Interface

USB(Drive-Free), RS232, USB-COM

Physical  Parameters

Dimensions

118mm*95mm*144.4mm

Weight

390g

Material

ABS+PC

Cable Length

1.8M

  Environmental Parameters

Operating Temperature

-20℃ -60℃

Storage Temperature

-30℃ - 70℃

Relative Humidity

5% ~95% RH (non-condensing/non-freezing)

Shock Resistance

Withstands multiple times 1.5 meters drops to concrete

Electronic Parameters

Working Voltage

DC5V±5%

Operating Current

Standby Current 190mA; Working Current 240mA
