Megapixel Hands-free Omnidirectional 1D 2D Desktop Barcode Scanner, with Large Viewing Angel Imaging Platform Scan Various 1D & 2D Barcode.
Item NO.:
XB-8809HPayment:
EXW/FOBProduct Origin:
GuangzhouColor:
BlackProduct weight:
504gShipping Port:
Guangzhou/ShenzhenLead Time:
7-10daysXB-8809H barcode scanner is a high performance desktop scanner with leading CMOS image recognition technology and intelligent image recognition system. The large viewing angle of the scanning window is very suitable for large supermarket. It also used in many industries, such as Logistics, warehousing, retail store, airport check-in and so on.
Product Features：
|
Specification |
|
|
Performance Parameters |
|
|
Light Sources |
Red LED |
|
Supported symbologies |
1D: Codabar, Code 39, Code 32, Interleaved 2 of 5, NEC 2 of 5, Code 93,Straight 2 of 5, Industrial, Straight 2 of 5 lATA, Matrix 2 of 5, Code 11,Code 128,ISBT 128,GS1-128,UPC-A, UPC-EO, UPC-E1,EAN/JAN-13,EAN/JAN-8, ISBN, MSl, GS1 DataBar-Omnidirectional, GS1 DataBar Limited,GS1 DataBar Expanded. |
|
Scan Range |
20-310mm(EAN 13 13mil,Pcs=90%) |
|
System compatibility |
Linux, Android, Windows XP/7/8/10 |
|
Minimum recognition accuracy |
Code 39 4mil |
|
Motion tolerance |
4 meters/second |
|
Scan Mode |
Automatic Induction Scanning |
|
Image(Pixels) |
1024 pixels(H) x 1280 pixels(V) |
|
Print contrast |
20% minimum reflective difference |
|
Recognition angle range |
Turn ±360°, Elevation ±65°, Declination ±65° |
|
Man-machine Interaction |
Indicator light: Red and blue dual color indicator light: Blue light flashing code reading prompt, blue light power indicator; Red light: turn off QR code reading. Buzzer: start prompt, read code prompt;Key: switch three tones; 1D code switch. |
|
Interface |
USB(Drive-Free), RS232, USB-COM |
|
Physical Parameters |
|
|
Dimensions |
150mm*97mm*148mm |
|
Weight |
540g |
|
Material |
ABS+PC |
|
Cable length |
1.8M |
|
Environmental Parameters |
|
|
Operating Temperature |
-20℃ - 60℃ |
|
Storage Temperature |
-30℃ - 70℃ |
|
Humidity |
5% to 95% RH.Non-condensing |
|
Shock Resistance |
Withstands multiple times 1.5 meters drops to concrete |
|
Ambient Light |
0-100,000LUX |
|
Electrical Parameters |
|
|
Voltage |
DC5V±5% |
|
Current |
Standby current 190mA, Working current 240mA |
Leave A MessageThe 2d desktop barcode scanner is new design item ,quick speed and accurate reading barcode. Ultra wide scan wide angle and ultra far reading distance. Square code reader is scan scan more 1d and 2d barcode,widely be used in fixed device wechat ,Alipay ,supermarket etc.,
1d 2d desktop barcode Scanner can easily capture bar codes 1D, 2D on labels, paper, and mobile phone Sensitive and accurately Plug and Play, no need for any driver or software. the scanner into USB port of windows/Linux PC, Mac,etc.
The 2d desktop barcode scanner is new design item ,compatible with Linux,Android,Windows XP,7,8,10,MAC. Quick and accurate reading of universal 1D and 2D code.
The 2D omni Barcode Scanner is the hot selling item, it is support multi-language ,which is can scan various 1d code and QR code .High quality withstands multiple times 1.5meters drops to concrete.
The 2d desktop scanner is a excellent 1d/2d reading performance , supports 1d and 2d barcodes.Fast and accurate decoding to improve user experience and support all kinds of bar code scanning.
Syble XB-8808G 2D Desktop Barcode Scanner employs advanced 1.3-megapixel imaging CMOS technology to quickly and accurately read traditional 1D barcodes and 2D codes like QR and DataMatrix. It delivers outstanding performance even with screen codes, damaged, or blurred barcodes. Its rugged construction complements a compact, stylish form factor, saving space while withstanding high-frequency, high-intensity work environments. Plug-and-play functionality ensures seamless compatibility with mainstream operating systems and business software, greatly simplifying deployment. Designed for diverse applications including retail, logistics, office, and healthcare.
This hands-free 2d barcode scanner can capture 1D, QR, and 2D barcode on paper and screen easily. The scanner’s sleek and elegant design blends in retail environments seamlessly, providing superior-performance scanning of all printed barcodes, and digital barcode on any smart device.
This 2d desktop barcode reader with professional technology, newly upgraded decoding chip. Scanning and reading 1D/2D high-density barcode information. Improve the real-time, accuracy and efficiency of data acquisition. Greatly improve the speed of scanning code, and has a large screen recognition angle, adjustable scanning window elevation angle ±65°, rotation angle ±360°, deflection angle ±65°, which meet diversified scanning application scenarios.
